Introducing the Switch Boot!
Origin Story:
I can't speak for everyone else but I certainly can relate to this meme. Especially during the early days of Nintendo Switch™ Repair. Damaged charging ports are one of the most common repairs for these consoles. Many times, the port is so damaged that the pins inside the port are shorting together. This can cause a multitude of issues if power is applied by plugging in the charger. Usually, the USB-C Controller (M92T36) is the first victim. Typically, after that chip shorts out, the console will no longer boot and it will often display an error: 2101-0001. Eventually, I realized that I needed to boot up every Nintendo Switch prior to replacing the charging port. That way I can check for any further issues. An easy way to do that was by using a charged battery or a DC Power Supply with BMS board. I wanted a more efficient way to do this and that is what led to the design and creation of the Switch Boot™ 🥾
Overview:
Switch Boot is the first of its kind, power adapter designed for Nintendo Switch repairs and diagnostics. It allows you to power the console from virtually any USB power source, eliminating the need for a “tester” battery or sketchy BMS hookup 😅. Its small form factor makes for a great addition to any game console repair workbench.
- Plug-and-Play Design - Plug in the output to the Nintendo Switch battery terminal, input side to a USB power source, trigger the power switch, and wait for the console to boot! 🥾
- USB-C input is configured to default to 5V, but it safely operates with an input voltage range of 5V-28V.
- Output is stepped down to ~4.2V, which mimics a charged battery.
- Connect to a USB power meter to monitor current draw patterns.
- Designed and assembled in the USA 🇺🇸
Features:
- Universal Compatibility - Works with all current Nintendo Switch models (OLED/V2/V1/Lite).
- USB-C Convenience - Works with virtually any USB-C to C and USB-A to C cable.
- No DC Power Supply Required - All you need is a good quality USB-C cable and usb charger (5V ≥2A).
- Output Power LED Indicator.
- Compact and efficient design.
- Custom harness for a unique look.
- Proprietary Schematic and PCB Design.
- Safety Features—SCP, OCP, OVP, Thermal Shutdown, Output Rail Fuse.
FAQs:
Q: Can I use this without opening the console?
No, you MUST open the console to gain access to the battery terminal on the motherboard.
Q: Can this be used as a permanent battery replacement?
No, this is a tool that is intended for diagnostic and repair use only, not as a long-term battery substitute.
Q: Why is the battery percentage not showing 100% when using the Switch Boot?
There is no “State of Charge” circuit in the Switch Boot, so it is normal for the console to display a percentage other than 100%.
Q: I see TWO output connections, can I plug in two consoles at the same time?
No, the Switch Boot is designed to be used with one console at a time.
Q: What happens if a charger is plugged in while Switch Boot is in use?
Firstly, it is not advised to do this since the Switch Boot is not a direct replacement for a battery. However, the Nintendo Switch™ will detect the charger and display a charging symbol, but no current is sent to the Switch Boot because it is already providing stable power to the console. The console’s power management system recognizes this as a charged battery.
Is this an official Nintendo product?
No, Switch Boot is a third-party repair tool designed for technicians and console repair specialists. It is not affiliated with or endorsed by Nintendo.
| Input Connector | Female USB-C Receptacle |
| Operating Input Voltage | 5V-28V |
| Input Voltage Max. | 30V |
| Output Connector | 5/3 PIN JST Conn. |
| Output | 4.3V⎓2A Max |
| Product Length | 35mm |
| Product Width | 13mm |
Disclaimer: Switch Boot™ is not affiliated with or endorsed by Nintendo. All trademarks are the property of their respective owners.
